Electroless Nickel Glass To Metal Seals Hermetic Industrial IATF Certification

Industrial Electroless Nickel Glass-Metal Seals For Durable Performance

Product Description:

We can give different types of sintered seal connector terminals in accordance with the requirements of customers. The technical parameters of our produced terminals are as follows:

Material: 45 Steel
Hi-pot: 3000v leak current ≤ 0.5MA
IR: 1000V IR > 1000MΩ
Leak Test: 4MPa N2 pressure No leak
Burst Test: 5MPa No leak
Operating Temperature Range: -70°C - 300°C

Features:

• Product Name: Glass To Metal Seals
• Pressure Range: 2- 5MPa
• Application: Industrial
• Temperature Range: -70℃ To 300℃
• Material: 45 Steel
• Voltage Rating: 12V-540V
• Metal-to-Glass Bond Seals
• Glass-to-Metal Bond Seals
• Glass-to-Metal Bond Seals

Technical Parameters:

All products of the company are electroless nickel plating, using an environmentally friendly method. The coating thickness is 3-5 microns. This environmentally friendly nickel coating does not contain hazardous substances, such as mercury, lead, cadmium, and hexavalent chromium. Performance reaches EU standards and has been certified by SGS environmental testing report. It also allows for electrical connections.

Applications:

SSCore is a well-known brand in the metal seal connectors industry. Our products are made of 45 steel and certified to IATF16949 standard. With a wide temperature range from -70℃ to 300℃ and a pressure range from 2- 5MPa, our metal seal connectors are widely used in various industrial applications. Our metal-to-glass seals have the advantages of superior sealing performance, high corrosion resistance, and excellent insulation. The surface of the metal-to-glass seals is treated with electroless nickel for increased durability. We offer competitive prices, with minimum order quantity of 5 pcs and delivery time of 7-14 work days. We have the supply ability of 50w pieces a month and accept payment terms such as L/C, D/A, T/T, D/P. All products come in vacuum package for better protection.

Customization:

Support and Services:

At ABC Company, we offer comprehensive technical support and service for Glass to Metal Seals. Our knowledgeable team of engineers is available to answer any questions you may have about our products. We provide guidance on selecting the right seal for your application and help you troubleshoot any issues you may be having. Our team of experts is also available to provide custom solutions to meet your specific needs.

We also provide on-site installation and training for our Glass to Metal Seals. Our experienced technicians will ensure that your product is properly installed and that you have the skills necessary to properly use it. We can also provide guidance on maintenance and troubleshooting to help optimize the life of your seal.

At ABC Company, we strive to provide you with the best technical support and service for Glass to Metal Seals. If you have any questions or would like to learn more about our products, please don’t hesitate to contact us.
